Edition Turbine Products

JB-180-Gold Edition from 000,00 EUR

The JB180 Gold Edition is based up the advancement of the legendary JB180. The turbine is equipped with a 5 axle CNC milled compressor. This is made of special high-strength aluminum alloy. The new combustion chamber, compressor and the new electronic spend a very fast acceleration, excelent quiet running, as well as extraordinary dynamics to the turbine. The engine is provided as a standard with a starter and with all accessories necessary for the installation less battery. Test run certificate, delivered. The turbine is only available with kerosene start. The kerosene burner is fully integrated. The provided ECU (Electronic Controll Unit) is using a special software for the JB180-Gold edition and need only one receiving channel. For current supply we recommend a 3S Lipo with ca.2500mAh and max.12Volts. We give two years to warranty on the complete turbine.


• proven design, very maintenance-poor
• easy operation through integrated 12 V kerosene burner
• autocalibration, turbine calibrates itself automatically
• optimized kerosene consumption with approx. 500 - 550ml/min
• super fast acceleration, very dynamically

Technical data:

Description                               Order number                 Price / Germany incl. 19% VAT

Turbine J66HP Set from 000,00 EUR

This is a powerful engine in the 85 Newton range. We produce this turbine since 1997 and therefor are all spare parts available. The J66HP is a full auto start system and is delivered with all needed accessories (less battery). Also the fuel consumption is optimized. The ProJet ECU, which is optimized for the J66HP, requires only one receiver channel to operate the turbine. You can choose between kerosene start or propane start.All the hardware parts are manufactured in-house by Behotec using only the very best aircraft grade materials. All aluminium parts are anodized black or natural silver. There are NO plastic parts used on Behotec turbines. The J66HP is a contest proven design and will power models up and above the 33 lbs class. Best modell weight class for this turbine is between 8kg and 14kg. All our turbines come with a run/calibration certificate and are covered by a two - year warranty.

Turbine set contents:


J-66HP turbine with electric starter

ProJet ECU (engine control unit), GSU ( ground support unit )

Set of cables, ProJet manuals

Kerosene - & propane valves

Behotec kerosene pump, type P-7

Kerosene filter, propane filter, feltclunk, clunk adapter

tubings for kerosene & propane, glowplug wrench,

Tygon tubing

Onboard gas tank

Turbine mount

Turbine handbook

Testrun certificate

Specifications:

Diameter:  112 / 113mm

Length:   315mm

max.thrust:   85N - 20lbs @ 120.000 rpm

min.thrust:  5,5N - 1,3lbs@ 35.000 rpm

Fuel consumption@ max.thrust:   360ml/min

exhaust gas temperature:   approx. 650°C

Fuel:  Jet A1, Diesel, Paraffin, (+5% turbine oil)

Turbine JB130 Set from 000,00 EUR

This is a powerful engine in the 130 Newton range. We produce this turbine since 1999 and therefor are all spare parts available. The JB130 is a full auto start system and is delivered with all needed accessories (less battery). The ProJet ECU, which is optimized for the JB130, requires only one receiver channel to operate the turbine. You can choose between kerosene start or propane start. All the hardware parts are manufactured in-house by Behotec using only the very best aircraft grade materials. All aluminium parts are anodized black or natural silver. There are NO plastic parts used on Behotec turbines. The JB130 is a contest proven design and will power models up and above the 20kg / 44 lbs class. Best modell weight class for this turbine is between 12kg and 18kg. All our turbines come with a certificate and are covered by a two year warranty.

Turbine set contents:


JB130 turbine with electric starter

ProJet ECU (engine control unit), GSU ( ground support unit )

Set of cables, ProJet manuals

Kerosene - & propane valves

Behotec kerosene pump, type P-7

Kerosene filter, propane filter, feltclunk, clunk adapter

tubings for kerosene & propane, glowplug wrench,

Tygon tubing

Onboard gas tank

Turbine mount

Turbine handbook

Testrun certificate

Specifications:

Diameter:  113mm

Length:   325mm

Weight:   1500g - 3,3lbs

max.thrust:   135N - 31lbs @ 120.000 rpm
min.thrust:  7N - 1,6lbs@ 35.000 rpm

Fuel consumption@ max.thrust:   500ml/min
Exhaust gas temperature:   approx. 650°C

Fuel:  Jet A1, Diesel, Paraffin, (+5% turbine oil

Turbine JB165 Set from 000,00 EUR

This is a powerful engine in the 165 Newton range. We produce this turbine since 2001 and therefor are all spare parts available. The JB165 is a full auto start system and is delivered with all needed accessories (less battery). The ProJet ECU, which is optimized for the JB165, requires only one receiver channel to operate the turbine. You can choose between kerosene start or propane start. All the hardware parts are manufactured in-house by Behotec using only the very best aircraft grade materials. All aluminium parts are anodized black or natural silver. There are NO plastic parts used on Behotec turbines. The JB165 is a contest proven design and will power models up and above the 20kg / 44 lbs class. Best modell weight class for this turbine is between 12kg and 20kg. All our turbines come with a certificate and are covered by a two year warranty.

Turbine set contents:


JB165 turbine with electric starter

ProJet ECU (engine control unit), GSU ( ground support unit )

Set of cables, ProJet manuals

Kerosene - & propane valves

Behotec kerosene pump, type P-7-2

Kerosene filter, propane filter, feltclunk, clunk adapter

tubings for kerosene & propane, glowplug wrench,

Tygon tubing

Onboard gas tank

Turbine mount

Turbine handbook

Testrun certificate

Specifications:

Diameter:  113mm

Length:   292mm

Weight:   1480g - 3,3lbs

max.thrust:   165N - 36,40lbs @ 120.000 rpm
min.thrust:  7-8N - 1,6lbs@ 35.000 rpm

Fuel consumption@ max.thrust:   550ml/min

Exhaust gas temperature:   approx. 680°C

Fuel:  Jet A1, Diesel, Paraffin, (+5% turbine oil)

Turbine JB180 Set from 000,00 EUR

This is a powerful engine in the 180 Newton range. We produce this turbine since 2005 and therefor are all spare parts available. The JB180 is a full auto start system and is delivered with all needed accessories (less battery). The ProJet ECU, which is optimized for the JB180, requires only one receiver channel to operate the turbine. You can choose between kerosene start or propane start. All the hardware parts are manufactured in-house by Behotec using only the very best aircraft grade materials. All aluminium parts are anodized black or natural silver. There are NO plastic parts used on Behotec turbines. The JB180 is a contest proven design and will power models up and above the 25kg / 56 lbs class. Best modell weight class for this turbine is between 15kg and 25kg. All our turbines come with a certificate and are covered by a two year warranty.

Turbine set contents:


JB180 turbine with electric starter

ProJet ECU (engine control unit), GSU ( ground support unit )

Set of cables, ProJet manuals

Kerosene - & propane valves

Behotec kerosene pump, type P-7-2

Kerosene filter, propane filter, feltclunk, clunk adapter

tubings for kerosene & propane, glowplug wrench,

Tygon tubing

Onboard gas tank

Turbine mount

Turbine handbook

Testrun certificate

Specifications:

Diameter:  113mm

Length:   320mm

Weight:   1580g - 3,5lbs

max.thrust:   180N - 40,50lbs @ 125.000 rpm
min.thrust:  7-8N - 1,7lbs@ 35.000 rpm

Fuel consumption@ max.thrust:   500ml/min

Exhaust gas temperature:   approx. 680°C

Fuel:  Jet A1, Diesel, Paraffin, (+5% turbine oil)
